8AWG 133 STRAND NICKEL-PLATED COND. MIL-W-22759/41 WIRE Roll of 1000Ft - $450 (Mechanicsville,Va)
condition:
new
QR Code Link to This Post
Call 80FOUr-40TWo-3niNe6FOUr.
M22759/41-8 8 gauge cable is part of our Mil-Spec Wire & Cable line of Wire & Cable. M22759/41-8 is composed of a 133/29 stranded nickel-plated copper conductor with cross-linked ethylene tetrafluoroethylene (XL-ETFE) insulation and jacket material. These cables are rated for a voltage of 600 volts, have a maximum temperature of 200°, and weigh approximately 60.3 lbs/MFT. MIL-W-22759/41 wire is suitable for use in aircraft engines and in other military, government, or civilian applications where abrasion is present.
Attributes
No. of Cond. 1
Approx LBS/MFT 60.30
AWG Size 8
Cond. Material Nickel-Plated Copper
Conductor Stranding 133/29
Insul. Material Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE)
Jacket Material Cross-Linked Ethylene Tetrafluoroethylene (XL-ETFE)
M27500 Component SM
Max O.D. (in) 0.203
Max. Temp 200C
Mil-Spec M22759/41
Min O.D. (in) 0.187
Min. Temp -55C
No. of Strands 133
SAE Spec AS22759/41
Strand Size 29
Voltage 600
